Brushless Motor Sensorless Amphibious Fully Waterproof motor 65162 120KV | 100KV 6000W for Efoil | Electric surfboard | Electric Hydrofoil | Foilsurf | Surffoil | RC Boat | Esurf | Jetski | Jetboard

kv option

Brushless Inrunner Motor Amphibious Fully Waterproof | 65162 120KV | 100KV 6000W  for Efoil | Ejet boards | Ebike with Propeller

Compatible with:300A 60V ESC

65162 EFOIL Kits:65162 motor+300AESC+WH4 Remote

Product Spec:

65162-120KV

Shell Dimension)(mm)

D65.5XL161.5

Construction

18N/6P

chip dimension

D61xd34xL100/0.2

magnets dimension& spec

R16XL101(45SH) Magnet stagger10°

shaft Extension length(mm)

62.5

shaft diameter(mm)

Φ12*M8*grooves

Plug

8.0mm

Extension wire length(mm)

1300

Appearance color

Full black

wires

0.38X28条X5.1m

winding

3Y

resistance(mΩ)

52.8/53.1/52.8

Inductance(uH)

176.6/176.8/176.1

KV(RPM/V)

120KV

Current without sensor@8.4V

2.7A(actual measurement120KV)

Current with sensor@8.4V

NA

Timing

NA

Operation Voltage

9.5-14S(40-60V)

Speed/8.4V(RPM/8.4V)

1033

Max current(A)

120A

Max Power(W)

7.2KW

Insulation voltage/Leak current

AC500V/1MA/3S

efficiency

84%

working temp. limit

120℃

weight

2.8KG



65162-100KV

Shell Dimension(mm)

D65.5XL161.5

Motor Construction

18N/6P

Chip Spec

D61xd34xL100/0.2

magnets dimension& spec

R16XL101(45SH) Magnet stagger10°

Extension shaft length(mm)

62.5

shaft diameter(mm)

Φ12*M8*grooves

Plug(mm)

8.0mm

Extension wire length(mm)

1300

Appearance color

Full Black

Copper wire specifications

0.38X25条X6M

winding

3Y

resistance(mΩ)

68.9./69.3./68.8

Inductance(uH)

243.4/243.9/242.1

KV(RPM/V)

100KV

Current without sensor@8.4V

3.2A(actual measurement102KV)

Current with sensor @8.4V

NA

Timing

NA

Operation Voltage

9.5-12S(40-50.4V)

Speed/8.4V(RPM/8.4V)

865

max current(A)

120A

Max Power (W)

6KW

Insulation voltage/Leak current

AC500V/1MA/3S

efficiency

89%

working temp. limit

120℃

weight

2.8KG

Package inclued:

1*65162 ( 100KV or 120KV)

1*Propeller

3*8.0mm bullet connectors



Test Data Sheet:

Motor Drawing:



Application:

Efoil, Electric surfboard, Electric Hydrofoil,Foilsurf,Surffoil, RC Boat, Esurf, Jetski, Jetboard, etc.,
