Compatiable with :75V High Current 200A Waterproof ESC（Click The Link）

D65L162-100KV

Shell Dimension(mm)	D65.5XL161.5
Motor Construction	18N/6P
Chip Spec	D61xd34xL100/0.2
magnets dimension& spec	R16XL101(45SH) Magnet stagger10°
Extension shaft length(mm)	62.5
shaft diameter（mm)	Φ12M8grooves
Plug（mm)	8.0mm
Extension wire length(mm)	1300
Appearance color	Full Black
Copper wire specifications	0.38X25条X6M
winding	3Y
resistance(mΩ)	68.9./69.3./68.8
Inductance（uH）	243.4/243.9/242.1
KV（RPM/V)	100KV
Current without sensor@8.4V	3.2A(actual measurement102KV）
Current with sensor @8.4V	NA
Timing	NA
Operation Voltage	9.5-12S(40-50.4V)
Speed/8.4V（RPM/8.4V）	865
max current(A)	120A
Max Power （W）	6KW
Insulation voltage/Leak current	AC500V/1MA/3S
efficiency	89%
working temp. limit	120℃
weight	2.8KG

D65L162-195KV

Shell Dimension)(mm)	D65.5XL161.5
Construction	18N/6P
chip dimension	D61xd34xL100/0.2
magnets dimension& spec	R16XL101(45SH) Magnet stagger10°
shaft Extension length(mm)	62.5
shaft diameter（mm)	Φ12*M8
Plug	8.0mm Gold plug
Extension wire length(mm)	1300
Appearance color	All black
wires	0.38X40 article X3.1m
winding	222221Y
resistance(mΩ)	23.5/23.6/23.4
Inductance（uH）	68.1/68.2/68.4
KV（RPM/V)	195KV
Current without sensor@8.4V	4.0A(actual measurement191KV） Add water seal:3.6A
Current with sensor@8.4V	NA
Timing	NA
Operation Voltage	9.5-12S(40-50.4V)
Speed/8.4V（RPM/8.4V）	1632
Max current(A)	120A
Max Power（W）	6KW
Insulation voltage/Leak current	AC500V/10MA/3S
efficiency	＞85%
working temp. limit	120℃
weight	2.7KG

Packing List:
1. 65162 motor1;
2. Propeller1;
3. Gold plug3;
4. 4mm positioning pin1;
5. Gasket1;
6. M8 anti-drop nut2;
