Waterproof 75V High Voltage 100A High Current ESC 2KW Motor And Remote Control Kit For Surfboard




Manatee100  75V 100A VESC

Voltage: 75V maximum (recommended within 16S)

Current: 100A continuous, maximum 200A

Features:

 1、Based on the design of vesc75300 hardware principle.

 2、Using 6 mosfet  IRF7769L (100v 200A each).

 3、Independent gate drive.

 4、Independent power supply.

 5、Independent current sampling.

 6、Active filter circuit makes current sampling more accurate.

 7、Rich onboard interface.

 8、Independent two-way adc.

 9、Support VESC TOOL official 75300 firmware.

 10、The circuit is reasonable and stable.

2KW 140A Jet Propeller Paddle 65111 Electric Surfboard Motor

Specification:

Model type: 65111

Motor dimension: 65*111mm

Shaft:10mm

Motor stator slot: 12

Motor pole: 12

Motor KV:150

Motor Wire: 12AWG wire

Maximum voltage: 14S

Maximum current 140A

No-load current: 1.7A 142KV

Maximum power: 2kw and 1.5kw continuous

Resistance:115.8/114.9/114.7mΩ

Waterproof level:IP68

Weight:1.41kg

Remote Control

Specification:

Frequency: 2.4G

Voltage: 3.7V

Battery: lithium battery( inside)

Battery capacity: 400 mAh

Type of control: PWM

Output frequency: 1-2 millisecond

Throttle: 0-100%

Reset: zeroing automatically

Waterproof rate: PI67

Charging type: inductive charging

Inductive charger: ✔

charging cable: ✔

Power cable: USB

Charging voltage: 5V

Charging current: 500MA

Charging time: 2 H

Over charging protection: ✔

Effective range: 10M



Receiver:

operating voltage:5V

ESC power supply: ✔

External power interface: ✔

Frequency binding button: ✔

Out of control protection: ✔

Waterproof: no

Available channels:1

Frequency: 2.4G
